Marantz CD60 CD Player

$2,000
By Marantz

Description

HIGH-QUALITY CD PLAYER WITH MODERN DESIGN

Featuring contemporary styling and excellent sound

Built with high quality materials and Sound Master tuned to inspire listeners to discover new details in their favourite CDs.

Iconic design for modern CD enthusiasts

Key Features:

  • Unveil New Sounds In Classic CDs
    CD 60 is for those who cherish their CD collections and who seek to discover new details upon every listen

  • Luxurious Design Matches The Most Musical Sound
    Architectural design, modern materials, and intuitive operation make CD 60 as incredible to behold as to hear.

  • Pairs Beautifully With Marantz Amplifiers
    Complimentary visual design plus compatible technology make CD 60 a natural companion to MODEL 40n, MODEL 30, or other Marantz amplifiers

Rich, Warm, and Spacious Sound

Expertly tuned by the legendary Marantz Sound Master for The Most Musical Sound. CD 60 is the CD player your cherished collection deserves.

Optimized HDAM Circuit

In the CD 60, the proprietary HDAM circuit has been further optimized from its previous version by placing the parts symmetrically on the audio board and creating a more direct signal path. This update improves the sound stage from the previous models in pursuit of The Most Musical Sound.

High-Current Power Supply

The CD 60 power supply uses highspeed, high-current Schottky barrier diodes, higher value current storage capacitors and improved voltage regulators compared to predecessor models in this class. Oversize capacitors in the power supply improve current stability and reduced noise during highly demanding listening sessions.

Plays Hi-Res Audio USB Sources

The CD 60 can play back MP3, WMA, AAC and WAV, FLAC HD, ALAC, AIFF (up to 192-kHz/24bit), and DSD (up to 5.6- MHz) files from a connected USB storage device.

Specifications:

General

Unit (W x H x D mm) 442 x 129 x 396
Net weight 7.5kg
Packaging Dimensions (W x H x D mm) 525×249×511
Panel Color Available Colors: Silver/Gold and Marantz Black
Front (Center) Panel Aluminum

Specifications

Frequency response USB DSD: 2Hz - 50kHz (-3dB)
USB PCM: 2Hz - 50kHz (-1.5dB)
CD: 2Hz - 20kHz
Total Harmonic Distortion USB DSD: 0.0006%
USB PCM 24bit: 0.0005%
CD: 0.0015%
Signal to Noise Ratio USB DSD: 110dB
USB PCM 24bit: 118dB
CD: 118dB
Dynamic Range USB DSD: 110dB
USB PCM 24bit: 118dB
CD: 101dB
Line Output Level 2.2Vrms
Headphone Output Level 28mW / 32 ohms
Power Consumption 38W
at Standby 0.3W

Audio Feature

HDAM New HDAM + HDAM-SA2
Power Transformer EI
Headphone Amp High slew rate op-amp
+ HDAM-SA2
H/P Amp Gain Setting Yes (Low / Mid / High)
Digital Filter Filter 1, 2 Selectable

Connectivity / Playback Capability

CD Compatibility CD / CD-R/RW / WMA / MP3 / AAC
Data Disc Compatibility DSD / WAV / ALAC
Fixed Analog Output (RCA) 1 (Gold Plated)
Optical input / output (Maximum Support) 0 / 1
Coaxial input / output (Maximum Support) 0 / 1
Headphone Output 1
Remote Control Bus Terminal Yes (RC-5 In / Out)
w/ External / Internal Select Switch
USB A 1 (Front)
Mass Storage Class
5V/1A
Support format FAT 16/32
USB-A: FLAC / WAV / AIFF / ALAC / DSD Yes / Yes / Yes / Yes
DSD Native Playback Yes
USB Firmware Update Yes

Easy to use

Remote Controller System Remote
(Amp and CD Player Control)
Unit control (Button) POWER, Play/Pause, Stop, Input, Open/Close, Fwd, Rev
Unit control (Knob) 1
Phones Level
Dimmer for Front Display Bright / Dim / Dark / Off
Control with App via Network Player (Use Remote Control Bus) Yes
Last Function Memory Yes
Timer Play (Need external audio timer) Yes
On/Off selectable in Menu
Auto Standby Mode Yes
Other Stereo RCA Cable x1
Remote connector cable x1
Accessory Box Yes
Battery Yes (AAA x2)
Power Cord Yes
